Sizes 17.5, 18.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame and
1x-specific stays, ABP, Boost148, Knock Block steerer
stop, EVO link, E2 tapered head tube, Mino Link,
Control Freak internal routing, Carbon Armor, PF92,
ISCG 05, G2 Geometry, 160mm travel
Front suspension RockShox Lyrik RC, Dual Position
Air, Charger Damper, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 130mm/160mm travel
Rear suspension RockShox Super Deluxe
RC3, 230x57.5mm
Shifters SRAM X1, 11-speed
Rear derailleur SRAM X1, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank SRAM X1 1200, 32T Direct Mount X-Sync
Wheels Bontrager Line Comp 30, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager SE4 Team Issue, Tubeless Ready, Core
Strength sidewalls, aramid bead, 29x2.40"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager Drop Line 125, under-bar
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line, 35mm, 27.5mm rise,
780mm width
Stem Bontrager Line, Knock Block, 35mm, 0 degree
Headset FSA Knock Block IS-2, E2, sealed
alloy cartridge
Brakeset SRAM Guide R hydraulic disc
Key Features
••150/160mm travel + 29er speed + low and
long geo = Enduro weapon
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••ABP keeps your suspension active while
you’re on the brakes
••Straight Shot stiffness, Knock Block
frame defence
