Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame Alpha Platinum Aluminium, Boost148,
Midstay, E2 tapered head tube, internal derailleur and
dropper post routing, PF92, Stranglehold dropouts,
G2 Geometry
Front suspension Manitou Magnum 34 Comp, air
spring, E2 tapered steerer, Boost110, G2 Geometry
w/51mm offset, 120mm travel
Shifters SRAM GX, 11-speed
Rear derailleur SRAM GX, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank SRAM X1 1200, 30T Direct Mount X-Sync
Wheels Bontrager sealed bearing hubs, alloy axle
Boost110 front, Boost148 rear; SUNringlé Duroc 50 SL
28-hole rims
Tyres Bontrager Chupacabra, Tubeless Ready, aramid
bead, 29x3.00"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager alloy, 2-bolt head, 31.6mm,
8mm offset
Handlebar Bontrager Rhythm Elite, 31.8mm, 15mm
rise, 750mm width
Stem Bontrager Rhythm Comp, 31.8mm, 7 degree
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset SRAM Guide R hydraulic disc
Key Features & Upgrades (?)
••120mm travel and 29+ wheels let you roll
over anything
••Shorter chainstays give you a spirited,
lively ride
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••The stranglehold dropout gives you options:
29+, 27.5+, or 29er
Manitou Magnum 34 Comp fork
Bontrager sealed bearing hubs
SRAM X1/GX 1x11 drivetrain
SRAM Guide R brakes
