Sizes S, M, L, XL
Frame OCLV Mountain Carbon w/InTension main
frame, OCLV stays, ABP, Full Floater, HexMC carbon
EVO Link, E2 tapered head tube, Mino Link, integrated
frame protection, internal control routing, MicroTruss,
Carbon Armor, ISCG mount, 210mm travel
Front suspension Fox Factory 40 FIT RC2, air spring,
Kashima Coat, hi/lo speed compression, 20mm thru
axle, 203mm travel
Rear suspension Fox DHX2 SLS, high/low speed
rebound adjust, high/low speed compression adjust,
(S 400lb; M/L 450lb; XL 500lb spring), tuned by Trek
Suspension Lab, 8.75x2.75"
Shifters Shimano Saint, 10-speed
Rear derailleur Shimano Saint, Shadow Plus
Cassett e Shimano Ultegra, 11-25, 10-speed
Crank Shimano Saint, 36T
Pedals Wellgo MG-1, magnesium body, Cro-Mo axle,
replaceable pins
Wheels DT Swiss FR1950 Gravity Classic, 110x20 front,
157x12 rear
Tyres Bontrager G4 Team Issue, 27.5x2.35"
Saddle Bontrager Evoke 3, titanium rails
Seatpost Bontrager Rhythm Elite, 2-bolt head, 31.6mm,
zero offset
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm,
27.5mm rise, 820mm width
Stem Race Face Atlas Direct Mount, 35mm
Headset Cane Creek alloy integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Saint hydraulic disc
Key Features & Upgrades (?)
••Fast 27.5 wheels get you down the
mountain first
••OCLV Mountain Carbon with Carbon Armor is
downhill tough
••Race Shop Limited: Pro-level bikes for the
most discerning riders
••Mino Link adjustable geometry lets you fine
tune your ride
OCLV Mountain Carbon frame
Fox Factory 40 RC2 air fork
Fox DHX2 SLS 4-way adjustable shock
DT Swiss FR1950 Gravity Classic wheels
