Sizes S, M, L, XL
Frame Alpha Platinum Aluminium, ABP, Full Floater,
EVO Link, E2 tapered head tube, Mino Link, integrated
frame protection, internal control routing, MicroTruss,
downtube guard, ISCG Mount, 210mm travel
Front suspension RockShox BoXXer RC, coil spring
(S, M red; L, XL blue), low speed compression,
internal preload, Motion Control IS, 20mm Maxle DH,
200mm travel
Rear suspension Fox Performance VAN, externally
adjustable rebound and low-speed compression; (S
400lb; M 450lb; L 500lb; XL 500lb spring), tuned by
Trek Suspension Lab, 8.75x2.75"
Shifters SRAM X0 DH, 7-speed
Rear derailleur SRAM X01, Roller Bearing Clutch
Cassett e SRAM PG-720, 11-25, 7-speed
Crank Truvativ Descendant, 36T
Pedals Wellgo MG-1, magnesium body, Cro-Mo axle,
replaceable pins
Wheels DT Swiss FR2150, 110x20 front, 157x12 rear
Tyres Bontrager G4 Team Issue, 27.5x2.35"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager Rhythm Elite, 2-bolt head, 31.6mm,
zero offset
Handlebar Bontrager Line, 35mm, 27.5mm rise,
820mm width
Stem Race Face Chester Direct Mount, 35mm
Headset FSA Orbit, sealed cartridge bearing, 1-1/8"
top, 1.5" bottom
Brakeset SRAM CODE R hydraulic disc
Key Features & Upgrades (?)
••Fast 27.5 wheels get you down the
mountain first
••Exclusive suspension tech with ABP and
Full Floater
••Mino Link adjustable geometry lets you fine
tune your ride
••Internal routing and integrated
frame protection
Fox Performance VAN shock
SRAM X0/X01 DH drivetrain
SRAM CODE R brakes
Bontrager Line 35mm handlebar
Trek Black
