Sizes 15.5, 17.5, 19.5, 21.5"
Frame Alpha Platinum Aluminium, ABP, Full Floater,
EVO link, E2 tapered head tube, internal derailleur and
dropper routing, downtube guard, PF121, 197x12 hub
spacing, 120mm travel
Front suspension RockShox Bluto RL, Solo Air, TurnKey
lockout, E2 tapered steerer, 150x15mm Maxle Lite,
120mm travel
Rear suspension Fox Performance Float EVOL,
RE:aktiv 3-position damper, tuned by Trek Suspension
Lab, 7.25x1.875"
Shifters SRAM GX, 11-speed
Rear derailleur SRAM GX, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank Race Face Aeffect, 28T Direct
Mount Narrow-Wide
Wheels Bontrager alloy sealed bearing hubs;
150x15 front, 197x12 rear, SUNringlé Mulefüt 80mm
32-hole w/cutout rims
Tyres Bontrager Hodag, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x3.80"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost KS eThirty Integra, remote lever, 2-bolt head,
31.6mm, zero offset, internal routing
Handlebar Bontrager Line, 35mm, 15mm rise,
750mm width
Stem Bontrager Line, 35mm, 0 degree
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset SRAM Level T hydraulic disc
Key Features
••Light, super-strong Alpha Platinum
Aluminium frame
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Faster 27.5 x 4 wheels bounce less and
roll farther
••Go tubeless with Bontrager TLR for
trail-hugging confidence
