Sizes 15.5, 17.5, 19.5, 21.5"
Frame OCLV Mountain Carbon, E2 tapered head tube,
internal derailleur and dropper post routing, Carbon
Armour, PF121, 197mm Stranglehold adjustable
thru-axle dropouts
Fork Bontrager Haru Pro, OCLV Carbon lowers,
carbon E2 tapered steerer, 100mm suspension
corrected, 15x150mm
Shifters SRAM X1, 11-speed
Rear derailleur SRAM X01, Roller Bearing Clutch
Cassett e SRAM XG-1175, 10-42, 11-speed
Crank Race Face Next, 30T Direct
Mount Narrow-Wide
Wheels Trek Wampa Carbon 80 SL, Tubeless Ready,
150x15 front, 197x12 rear
Tyres Bontrager Barbegazi, Tubeless Ready, Inner
Strength sidewalls, 120tpi, aramid bead, 27.5x4.50"
Saddle Bontrager Montrose Elite, hollow titanium rails
Seatpost Bontrager Pro, OCLV Carbon, 31.6mm,
5mm offset
Handlebar Bontrager Race X Lite, OCLV Carbon,
31.8mm, 15mm rise, 750mm width
Stem Bontrager Pro, 31.8mm, 7 degree.
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset SRAM Guide RS hydraulic disc
Key Features & Upgrades (?)
••OCLV Mountain Carbon frame is ultra light,
ultra tough
••Ride your way: accommodates 26" x 5" or
27.5" x 4.5" wheels
••Trail-optimised geometry for the best
handling in any season
••Go tubeless with Bontrager TLR for
trail-hugging confidence
Bontrager Haru Pro fork w/carbon steerer
Trek Wampa carbon wheels
SRAM X1/X01 drivetrain
Race Face Next carbon crank
