Sizes 15.5, 17.5, 19.5, 21.5"
Frame Alpha Platinum Aluminium, E2 tapered
head tube, internal derailleur and dropper post
routing, PF121, 197mm Stranglehold adjustable
thru-axle dropouts
Fork Bontrager Haru, OCLV Carbon lowers,
E2 tapered steerer, 100mm suspension
corrected, 15x150mm
Shifters SRAM GX, 11-speed
Rear derailleur SRAM GX, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank Race Face Aeffect, 28T Direct
Mount Narrow-Wide
Wheels Bontrager sealed bearing hubs, 150x15 front;
197x12 rear; SUNringlé Mulefüt 80mm 32-hole
cutout rims
Tyres Bontrager Barbegazi, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 26x4.70"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager alloy, 2-bolt head, 31.6mm,
8mm offset
Handlebar Bontrager Rhythm Elite, 31.8mm, 15mm
rise, 750mm width
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset SRAM Level T hydraulic disc
Key Features & Upgrades (?)
••Ride your way: accommodates 26" x 5" or
27.5" x 4.5" wheels
••Light, super-strong Alpha Platinum
Aluminium frame
••Trail-optimised geometry for the best
handling in any season
••E2 head tube gives you precise handling in
gnarly conditions
Bontrager Haru carbon fork
SRAM GX 1x11 drivetrain
Race Face Aeffect crank
SRAM Level T brakes
