Sizes 15.5, 17.5, 19.5, 21.5"
Frame Alpha Platinum Aluminium, E2 tapered
head tube, internal derailleur and dropper post
routing, PF121, 197mm Stranglehold adjustable
thru-axle dropouts
Fork Alpha Platinum Aluminium, IS brake mount,
E2 tapered aluminium steerer, 100mm suspension
corrected, 5x135mm
Shifters Shimano Deore, 10-speed
Front derailleur SRAM X5, low direct mount
Rear derailleur Shimano Deore, Shadow Plus
Cassett e Shimano HG50, 11-36, 10-speed
Crank Race Face Ride, 36/22
Wheels Bontrager sealed bearing hubs, 135x5 front;
197x12 rear; SUNringlé Mulefüt 80mm 32-hole
cutout rims
Tyres Bontrager Barbegazi, Tubeless Ready, Inner
Strength sidewalls, 120tpi, aramid bead, 26x4.70"
Saddle Bontrager Evoke 1.5
Seatpost Bontrager alloy, 2-bolt head, 31.6mm,
8mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise,
750mm width
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset SRAM Level hydraulic disc
Key Features
••Ride your way: accommodates 26" x 5" or
27.5" x 4.5" wheels
••Light, super-strong Alpha Platinum
Aluminium frame
••Trail-optimised geometry for the best
handling in any season
••E2 head tube gives you precise handling in
gnarly conditions
