Sizes 15.5, 17.5, 18.5, 19.5, 21.5”
Frame Alpha Platinum Aluminium, ABP, Boost148,
EVO link, E2 tapered head tube, Knock Block steerer
stop, internal derailleur and dropper post routing,
130mm travel
Front suspension RockShox Sektor Silver RL, Solo
Air, TurnKey lockout, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 130mm travel
Rear suspension RockShox Deluxe RL, tuned by Trek
Suspension Lab, 230x57.5mm
Shifters Shimano Deore XT, 11-speed
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano M7000 SLX, 11-42, 11-speed
Crank Miranda Delta, 15T
Pedals Wellgo nylon platform
Wheels Bontrager sealed bearing, alloy axle
hubs, Boost110 front, Boost148 rear; Bontrager
XR850 32-hole 28mm wide double-walled rims
Tyres Bontrager XR3 Expert, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x2.35”
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager SSR, 2-bolt head, 31.6mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 5mm rise,
750 width
Stem Bontrager Rhythm Comp, Knock Block, 31.8mm,
0 degree
Headset FSA Knock Block IS-2, E2, sealed
alloy cartridge
Brakeset Shimano M615 hydraulic disc, 203mm
front/180mm rear rotors
Controller Bosch Intuvia Performance
Batt ery Bosch Powerpack Performance 500 downtube
Motor Bosch Performance CX
Key Features & Upgrades (?)
••Trek MTB legacy makes Powerfly a true
mountain bike
••Knock Block frame defence protects from
spinning handlebars
••ABP gives you more confidence and control
on the trail
••Powerful central-mount Bosch motor, for
speeds up to 20 mph or 25 km/h
Shimano Deore XT drivetrain
Shimano M615 brakes
Bontrager XR3 Expert TLR 2.35" tyres
Bontrager sealed bearing hubs
