Sizes 15.5, 17.5, 18.5, 19.5, 21.5”
Frame Alpha Platinum Aluminium, ABP, Boost148,
EVO link, E2 tapered head tube, Knock Block steerer
stop, internal derailleur and dropper post routing,
130mm travel
Front suspension RockShox Sektor Silver RL, Solo
Air, TurnKey lockout, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 130mm travel
Rear suspension RockShox Deluxe RL, tuned by Trek
Suspension Lab, 230x57.5mm
Shifters Shimano Altus M370, 9-speed
Rear derailleur Shimano Alivio M430
Cassett e Shimano HG200, 11-34, 9-speed
Crank Miranda Delta, 15T
Pedals Wellgo nylon platform
Wheels Bontrager alloy, alloy axle,
Boost110 front hub; Bontrager sealed bearing alloy
axle, Boost148 rear hub; Bontrager XR850 32-hole
28mm wide double-walled rims
Tyres Bontrager XR3, 27.5x2.20”
Saddle Bontrager Evoke 1.5
Seatpost Bontrager SSR, 2-bolt head, 31.6mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise
Stem Bontrager Rhythm Comp, Knock Block, 31.8mm,
0 degree
Headset FSA Knock Block IS-2, E2, sealed
alloy cartridge
Brakeset Shimano M315 hydraulic disc, 180mm rotors
Controller Bosch Intuvia Performance
Batt ery Bosch Powerpack Performance 500 downtube
Motor Bosch Performance CX
Key Features
••Trek MTB legacy makes Powerfly a true
mountain bike
••Knock Block frame defence protects from
spinning handlebars
••ABP gives you more confidence and control
on the trail
••Powerful central-mount Bosch motor, for
speeds up to 20 mph or 25 km/h
