Sizes 15.5, 17.5, 19, 21”
Frame Alpha Platinum Aluminium, E2 tapered head
tube, internal derailleur routing, Balanced Geometry
Front suspension RockShox Pike RC, Solo Air, Charger
Damper, E2 tapered steerer, Boost110, G2 Geometry
w/51mm offset, 100mm travel
Shifters SRAM EX1, 8-speed
Rear derailleur SRAM EX1, Roller Bearing Clutch
Cassett e SRAM XG-899 11-48, 8-speed
Crank SRAM EX1, 15T w/chainguard
Pedals Wellgo nylon platform
Wheels Bontrager sealed bearing alloy axle hubs,
Boost110 front; Bontrager Duster Tubeless Ready
32-hole rims
Tyres Bontrager XR3 Team Issue, Tubeless
Ready, Inner Strength sidewalls, 120tpi, aramid
bead, 29x2.30”
Saddle Bontrager Montrose Comp, chromoly rails
Seatpost RockShox Reverb, 2-bolt head, 31.6mm,
zero offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8”
top, 1.5” bottom
Brakeset SRAM Guide RS hydraulic disc, 200mm
front/180mm rear rotors
Controller Bosch Purion Performance
Batt ery Bosch Powerpack Performance 500 downtube
Motor Bosch Performance CX
Key Features & Upgrades (?)
••Powerful central-mount Bosch motor, for
speeds up to 20 mph or 25 km/h
••Alpha Platinum Aluminium frame with
additional Motor Armor protection
••Ready for extras like lights, mudguards,
racks, kickstand
••29” wheels roll faster, ride better, clear
more obstacles
RockShox Pike RC fork
SRAM EX1 drivetrain
RockShox Reverb dropper post
SRAM Guide RS brakes
