Sizes 15.5, 17.5, 19, 21"
Frame Alpha Platinum Aluminium, E2 tapered head
tube, internal derailleur routing, Balanced Geometry
Front suspension RockShox Reba RL, Solo Air, Motion
Control damper, remote lockout, E2 tapered steerer,
15mm Maxle Lite, G2 Geometry w/51mm offset,
100mm travel
Shifters Shimano Deore XT, 11-speed
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano Deore M8000 XT, 11-42, 11-speed
Crank RIDE+ aluminium 15T w/chainguard
Pedals Wellgo nylon platform
Wheels Bontrager sealed cartridge bearing alloy axle
hubs, 15mm front; Bontrager XR850 36-hole 28mm
wide double-walled rims
Tyres Bontrager XR3 Expert, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 29x2.30"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager SSR, 2-bolt head, 31.6mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset Shimano M615 hydraulic disc, 203mm
front/180mm rear rotors
Controller Bosch Intuvia Performance
Batt ery Bosch Powerpack Performance 500 downtube
Motor Bosch Performance CX
Key Features & Upgrades (?)
••Powerful central-mount Bosch motor, for
speeds up to 20 mph or 25 km/h
••Alpha Platinum Aluminium frame with
additional Motor Armor protection
••Ready for extras like lights, mudguards,
racks, kickstand
••29" wheels roll faster, ride better, clear
more obstacles
RockShox Reba RL fork w/15mm thru axle
Shimano Deore XT drivetrain
Bosch Powerpack Performance 500 battery
Shimano M615 brakes
