Sizes 15.5, 17.5"
Frame WSD Alpha Platinum Aluminium,
E2 tapered head tube, internal derailleur routing,
Balanced Geometry
Front suspension RockShox Recon Silver, coil spring,
preload, TurnKey lockout, E2 tapered steerer,
G2 Geometry w/51mm offset, 100mm travel
Shifters Shimano Altus M370, 9-speed
Rear derailleur Shimano Alivio M430
Cassett e Shimano HG200, 11-34, 9-speed
Crank RIDE+ aluminium 15T w/chainguard
Pedals Wellgo nylon platform
Wheels Shimano TX-505 front hub; Shimano
M3050 Center Lock rear hub; Bontrager
XR850 32-hole 28mm wide double-walled rims
Tyres Bontrager XR3, 27.5x2.35"
Saddle Bontrager Evoke 1 WSD
Seatpost Bontrager SSR, 2-bolt head, 31.6mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise,
690mm width
Stem Bontrager alloy, 31.8mm, 7mm rise,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset Shimano M315 hydraulic disc, 180mm rotors
Controller Bosch Intuvia Performance
Batt ery Bosch Powerpack Performance 500 downtube
Motor Bosch Performance CX
Key Features
••Powerful central-mount Bosch motor, for
speeds up to 20 mph or 25 km/h
••Alpha Platinum Aluminium frame with
additional Motor Armor protection
••Ready for extras like lights, mudguards,
racks, kickstand
••Women-specific saddle, bars and grips for
ultimate comfort
