Sizes 13.5, 15.5" (27.5" wheels); 17.5, 18.5"
(29" wheels)
Frame OCLV Mountain Carbon, IsoSpeed, E2 tapered
head tube, internal derailleur routing, balanced post
mount brake, PF92, Boost148 and G2 Geometry
on 29ers
Front suspension Fox Performance 32 Float, Step Cast,
Grip 2-position remote damper, E2 tapered steerer,
Boost110, G2 Geometry w/51mm offset on 29ers,
100mm travel
Shifters SRAM GX, 11-speed
Rear derailleur SRAM X1, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank SRAM X1 1200, 32T Direct Mount X-Sync
Wheels Bontrager Mustang Pro, Tubeless Ready,
Boost110 front, Boost148 rear (15.5: 142x12 rear)
Tyres Bontrager XR1 Expert, Tubeless Ready,
Inner Strength sidewalls, aramid bead, 29x2.20"
(15.5: 27.5x2.20")
Saddle Bontrager Ajna Comp WSD, chromoly rails
Seatpost Bontrager Rhythm Elite, 2-bolt head, 31.6mm,
zero offset
Handlebar Bontrager Race Lite, 31.8mm, 5mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset SRAM Level TL hydraulic disc
Key Features
••Smooth IsoSpeed decoupler: ride faster,
stronger, longer
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••OCLV Mountain Carbon frame is fast, light,
and trail tough
••Ride the fastest wheel that fits with Smart
Wheel Size
