Sizes 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5, 23"
(29" wheels)
Frame Alpha Platinum Aluminium, E2 tapered head
tube, internal derailleur routing, PF89.5, balanced post
mount brake, Closed Convert dropouts, G2 Geometry
on 29ers
Front suspension Fox Performance 32 Float, Step Cast,
Grip adjustable damper, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset on 29ers, 100mm travel
Shifters Shimano SLX M7000, 11-speed
Front derailleur Shimano SLX
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano SLX, 11-42, 11-speed
Crank Shimano Deore XT, 36/26
Wheels Bontrager Mustang Elite, Tubeless Ready,
Boost110 front, 142x12 rear
Tyres Bontrager XR1 Expert, Tubeless Ready,
Inner Strength sidewalls, aramid bead, 29x2.20"
(15.5: 27.5x2.20")
Saddle Bontrager Montrose Comp, chromoly rails
Seatpost Bontrager Rhythm Elite, 2-bolt head,
27.2mm, zero offset
Handlebar Bontrager Race Lite, 31.8mm, 5mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset Shimano Deore hydraulic disc
Key Features & Upgrades (?)
••Every feature of this XC race 29/27.5 is
designed to go fast
••Ride the fastest wheel that fits with Smart
Wheel Size
••Super-light hydro-formed aluminium frame is
built for speed
••Racy geometry gets you lower, shortens
the chainstays
Fox Performance Series fork
Bontrager Mustang Elite wheels
Shimano SLX/XT 2x11 drivetrain
Shimano Deore brakes
