Sizes 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5, 23"
(29" wheels)
Frame Alpha Platinum Aluminium, E2 tapered head
tube, internal derailleur routing, PF89.5, balanced post
mount brake, Closed Convert dropouts, G2 Geometry
on 29ers
Front suspension RockShox Reba RL, Solo Air spring,
Motion Control damper, remote lockout, E2 tapered
steerer, 15mm Maxle Lite, G2 Geometry w/51mm
offset on 29ers, 100mm travel
Shifters SRAM GX, 11-speed
Front derailleur SRAM GX
Rear derailleur SRAM GX, Roller Bearing Clutch
Cassett e SRAM PG-1130, 11-42, 11-speed
Crank SRAM GX 1000, 36/24
Wheels Bontrager sealed bearing, alloy axle hubs,
15mm front; Bontrager Mustang Elite Tubeless Ready
28-hole rims
Tyres Bontrager XR1 Expert, Tubeless Ready,
Inner Strength sidewalls, aramid bead, 29x2.20"
(15.5: 27.5x2.20")
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager alloy, 2-bolt head, 27.2mm,
8mm offset
Handlebar Bontrager alloy, 31.8mm, 5mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset Integrated, cartridge bearing, sealed, 1-1/8"
top, 1.5" bottom
Brakeset SRAM Level T hydraulic disc
Key Features & Upgrades (?)
••Every feature of this XC race 29/27.5 is
designed to go fast
••Ride the fastest wheel that fits with Smart
Wheel Size
••Super-light hydro-formed aluminium frame is
built for speed
••Racy geometry gets you lower, shortens
the chainstays
RockShox Reba RL fork w/15mm thru axle
SRAM GX 2x11 drivetrain
SRAM Level T brakes
