Sizes 13.5, 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5,
23" (29" wheels)
Frame Alpha Gold Aluminium w/semi-integrated head
tube, mechanically formed and butted tubing, race
geometry, internal front derailleur routing, rack and
mudguard mounts, G2 Geometry on 29ers
Front suspension RockShox Recon Silver RL, Solo Air
spring, TurnKey lockout, G2 Geometry w/51mm offset
on 29ers, 100mm travel (13.5" : 80mm travel)
Shifters Shimano Deore, 10-speed
Front derailleur SRAM X7
Rear derailleur Shimano Deore XT, Shadow
Cassett e Shimano HG50, 11-36, 10-speed
Crank Race Face Ride, 36/22
Pedals Wellgo nylon platform
Wheels Bontrager sealed bearing hubs; Bontrager
Mustang Elite Tubeless Ready 28-hole rims
Tyres Bontrager XR2, 29x2.20" front, 29x2.00" rear
(13.5 & 15.5: 27.5x2.20")
Saddle Bontrager Evoke 1.5
Seatpost Bontrager SSR, 2-bolt head, 27.2mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset 1-1/8" threadless, semi-integrated,
semi-cartridge bearings
Brakeset Shimano M365 hydraulic disc
Key Features & Upgrades (?)
••Race-ready spec: 2x drivetrain options,
lockout, hydraulic discs
••Light, precise race frame for a fast,
refined ride
••Ride the fastest wheel that fits with Smart
Wheel Size
••Extended size range gives you a better fit for
a better ride
RockShox Recon Silver Solo Air fork
Bontrager sealed bearing hubs
Race Face Ride crank
Shimano Deore/XT drivetrain
