Sizes 13.5, 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5,
23" (29" wheels)
Frame Alpha Gold Aluminium w/semi-integrated head
tube, mechanically formed and butted tubing, race
geometry, internal front derailleur routing, rack and
mudguard mounts, G2 Geometry on 29ers
Front suspension RockShox 30 Silver, coil spring,
preload, rebound, TurnKey lockout, G2 Geometry
w/51mm offset on 29ers, 100mm travel (13.5 :
80mm travel)
Shifters Shimano Acera M3000, 9-speed
Front derailleur Shimano Acera
Rear derailleur Shimano Acera M3000, Shadow
Cassett e Shimano HG20, 11-34, 9-speed
Crank Shimano M3000, 40/30/22
Pedals Wellgo nylon platform
Wheels Formula DC20 alloy front hub; Formula
DC22 alloy rear hub; Bontrager Connection 32-hole
double-walled rims
Tyres Bontrager XR2, 29x2.20" front, 29x2.00" rear
(13.5 & 15.5: 27.5x2.20")
Saddle Bontrager Evoke 1.5
Seatpost Bontrager SSR, 2-bolt head, 27.2mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise
Stem Bontrager Elite, 31.8mm, 7 degree,
Blendr compatible
Headset 1-1/8" threadless, semi-integrated,
semi-cartridge bearings
Brakeset Shimano M315 hydraulic disc
Key Features
••Race-ready spec: 2x drivetrain options,
lockout, hydraulic discs
••Light, precise race frame for a fast,
refined ride
••Ride the fastest wheel that fits with Smart
Wheel Size
••Extended size range gives you a better fit for
a better ride
