Sizes 13.5, 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5,
23" (29" wheels)
Frame Alpha Silver Aluminium w/semi-integrated
head tube, rack and mudguard mounts, G2 Geometry
on 29ers
Front suspension RST Gila, coil spring, preload,
mechanical lockout, G2 Geometry w/51mm offset on
29ers, 100mm travel (13.5: 80mm travel)
Shifters Shimano Altus M310, 8-speed
Front derailleur Shimano Tourney TY700
Rear derailleur Shimano Altus
Cassett e Shimano HG20, 12-32, 8-speed
Crank Shimano Tourney TY501, 42/34/24
Pedals Wellgo nylon platform
Wheels Formula alloy hubs, Bontrager Connection
32-hole double-walled rims
Tyres Bontrager XR2, 29x2.20" front, 29x2.00" rear
(13.5 & 15.5: 27.5x2.20")
Saddle Bontrager Evoke 1
Seatpost Bontrager SSR, 2-bolt head, 27.2mm,
12mm offset
Handlebar Bontrager alloy, 31.8mm, 15mm rise
Stem Bontrager Alloy, 31.8mm, 7mm rise,
Blendr compatible
Headset 1-1/8" threadless, semi-integrated,
semi-cartridge bearings
Brakeset Tektro M285 hydraulic disc
Key Features & Upgrades (?)
••Ride the fastest wheel that fits with Smart
Wheel Size
••Ride-tuned aluminium frame is XC light,
mountain tough
••Extended size range gives you a better fit for
a better ride
••Backed by Trek's limited lifetime warranty
RST Gila fork
Shimano Tourney TY700 front derailleur
Shimano Altus rear derailleur
Shimano Altus 3x8 shifters
