Sizes 13.5, 15.5" (27.5" wheels); 17.5, 18.5, 19.5, 21.5,
23" (29" wheels)
Frame Alpha Silver Aluminium w/semi-integrated
head tube, rack and mudguard mounts, G2 Geometry
on 29ers
Front suspension SR Suntour M-3030, coil spring,
preload, 75mm travel
Shifters Shimano Altus EF51, 7-speed
Front derailleur Shimano Tourney TY500
Rear derailleur Shimano Tourney TY300
Cassett e Shimano TZ21 14-28, 7-speed
Crank Shimano Tourney M131, 42/34/24
Pedals Wellgo nylon platform
Wheels Formula alloy hubs, Bontrager AT-550 36-hole
alloy rims
Tyres Bontrager XR2, 29x2.20" front, 29x2.00" rear
(13.5 & 15.5: 27.5x2.20")
Saddle Bontrager Evoke 1
Seatpost Bontrager SSR, 2-bolt head, 27.2mm,
12mm offset
Handlebar Bontrager Riser, 25.4mm, 30mm rise
Stem Bontrager alloy, 25.4mm, 15-degree
Headset 1-1/8" threadless, semi-integrated,
semi-cartridge bearings
Brakeset Tektro alloy linear-pull
Key Features
••Ride the fastest wheel that fits with Smart
Wheel Size
••Ride-tuned aluminium frame is XC light,
mountain tough
••Extended size range gives you a better fit for
a better ride
••Backed by Trek's limited lifetime warranty
