Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame and
1x-specific stays, ABP, Boost148, Knock Block steerer
stop, Full Floater, EVO link, E2 tapered head tube,
Mino Link, Control Freak internal routing, Carbon
Armor, PF92, ISCG 05, G2 Geometry, 130mm travel
Options Project One offers near-infinite customisation
of parts and paint schemes
Front suspension Fox Factory 34 Float, FIT4 3-position
damper, E2 tapered steerer, Kashima Coat, Boost110,
G2 Geometry w/51mm offset, 130mm travel
Rear suspension Fox Factory Float EVOL, RE:aktiv
3-position damper, Kashima Coat, tuned by Trek
Suspension Lab, 210x52.5mm
Shifters SRAM XX1 Eagle, 12-speed
Rear derailleur SRAM XX1 Eagle, Roller
Bearing Clutch
Cassett e SRAM XG-1295, 10-50, 12-speed
Crank SRAM XX1 Eagle, 32T Direct Mount X-Sync
Wheels DT Swiss XMC1200 Carbon, tubeless strips
and valves, Boost110 front, Boost148 rear
Tyres Bontrager XR3 Team Issue, Tubeless
Ready, Inner Strength sidewalls, 120tpi, aramid
bead, 29x2.40"
Saddle Bontrager Evoke RXL, carbon rails
Seatpost Bontrager Drop Line 125, under-bar
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm,
15mm rise, 750mm width
Stem Bontrager Line Pro, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset SRAM Guide Ultimate hydraulic disc
Key Features & Upgrades (?)
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
OCLV Mountain Carbon chainstay
Fox Factory Series fork and shock
DT Swiss XMC1200 carbon wheels
SRAM XX1 Eagle 1x12 drivetrain
