Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame and
seatstay, alloy chainstay, ABP, Boost148, Knock
Block steerer stop, Full Floater, EVO link, E2 tapered
head tube, Mino Link, Control Freak internal routing,
Carbon Armor, PF92, ISCG 05, G2 Geometry,
130mm travel
Options Project One offers near-infinite customisation
of parts and paint schemes
Front suspension Fox Performance 34 Float,
FIT4 3-position damper, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 130mm travel
Rear suspension Fox Performance Float EVOL,
RE:aktiv 3-position damper, tuned by Trek Suspension
Lab, 210x52.5mm
Shifters Shimano Deore XT M8000, 11-speed
Front derailleur Shimano Deore XT, high direct mount
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano Deore XT, 11-42, 11-speed
Crank Shimano Deore XT, 36/26
Wheels Bontrager Line Comp 30, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager XR3 Team Issue, Tubeless
Ready, Inner Strength sidewalls, 120tpi, aramid
bead, 29x2.40"
Saddle Bontrager Evoke 3, titanium rails
Seatpost Bontrager Drop Line 125, universal
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm,
15mm rise, 750mm width
Stem Bontrager Line Pro, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Deore XT hydraulic disc
Key Features & Upgrades (?)
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
OCLV Mountain Carbon seatstay
Fox Performance Series fork
Bontrager Line Comp wheels
Shimano Deore XT 2x11 drivetrain
