Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame, alloy
stays, ABP, Boost148, Knock Block steerer stop, Full
Floater, EVO link, E2 tapered head tube, Mino Link,
Control Freak internal routing, Carbon Armor, PF92,
ISCG 05, G2 Geometry, 130mm travel
Front suspension Fox Rhythm 34 Float, Grip
adjustable damper, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 130mm travel
Rear suspension Fox Performance Float EVOL,
RE:aktiv 3-position damper, tuned by Trek Suspension
Lab, 210x52.5mm
Shifters SRAM GX, 11-speed
Rear derailleur SRAM GX, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank SRAM X1 1200, 32T Direct Mount X-Sync
Wheels Bontrager Duster Elite, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager XR3 Expert, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 29x2.40"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost KS eThirty Integra, remote lever, 2-bolt head,
31.6mm, zero offset, internal routing
Handlebar Bontrager Line, 35mm, 15mm rise,
750mm width
Stem Bontrager Line, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Deore hydraulic disc
Key Features & Upgrades (?)
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
OCLV Mountain Carbon main frame
