Sizes 15.5, 17.5, 18.5, 19.5, 21.5, 23"
Frame Alpha Platinum Aluminium, ABP, Boost148,
Knock Block steerer stop, Full Floater, EVO link,
E2 tapered head tube, Mino Link, Control Freak
internal routing, downtube guard, PF92, ISCG 05,
G2 Geometry, 130mm
Front suspension Fox Performance 34 Float,
FIT4 3-position damper, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 130mm travel
Rear suspension Fox Performance Float EVOL,
RE:aktiv 3-position damper, tuned by Trek Suspension
Lab, 210x52.5mm
Shifters SRAM X1, 11-speed
Rear derailleur SRAM X1, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank SRAM X1 1200, 32T Direct Mount X-Sync
Wheels Bontrager Line Comp 30, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager XR3 Expert, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 29x2.40"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager Drop Line 125, under-bar
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line, 35mm, 15mm rise,
750mm width
Stem Bontrager Line, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset SRAM Guide RS hydraulic disc
Key Features & Upgrades (?)
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
Fox Performance Series fork
Bontrager Line Comp wheels
SRAM X1 1x11 drivetrain
SRAM Guide RS brakes
