Sizes 15.5, 17.5, 18.5, 19.5, 21.5, 23"
Frame Alpha Platinum Aluminium, ABP, Boost148,
Knock Block steerer stop, Full Floater, EVO link,
E2 tapered head tube, Mino Link, Control Freak
internal routing, downtube guard, PF92, ISCG 05,
G2 Geometry, 130mm
Front suspension Fox Rhythm 34 Float, Grip
adjustable damper, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 130mm travel
Rear suspension Fox Performance Float EVOL,
RE:aktiv 3-position damper, tuned by Trek Suspension
Lab, 210x52.5mm
Shifters Shimano Deore XT M8000, 11-speed
Front derailleur Shimano Deore, high direct mount
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano Deore XT, 11-42, 11-speed
Crank Shimano Deore XT, 36/26
Wheels Bontrager Duster Elite, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager XR3 Expert, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 29x2.40"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost KS eThirty Integra, remote lever, 2-bolt head,
31.6mm, zero offset, internal routing
Handlebar Bontrager Line, 35mm, 15mm rise,
750mm width
Stem Bontrager Line, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Deore hydraulic disc
Key Features & Upgrades (?)
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
Fox Rhythm Series fork
RE:aktiv shock
Shimano Deore XT 2x11 drivetrain
Shimano Deore brakes
