Sizes 15.5, 17.5, 18.5, 19.5, 21.5, 23"
Frame Alpha Platinum Aluminium, ABP, Boost148,
Knock Block steerer stop, Full Floater, EVO link,
E2 tapered head tube, Mino Link, Control Freak
internal routing, downtube guard, PF92, ISCG 05,
G2 Geometry, 130mm
Front suspension RockShox Revelation RL, Solo Air
spring, Motion Control damper, E2 tapered steerer,
Boost110, G2 Geometry w/51mm offset, 130mm travel
Rear suspension Fox Performance Float EVOL,
3-position damper, 210x52.5mm
Shifters Shimano Deore, 10-speed
Front derailleur Shimano Deore, high direct mount
Rear derailleur Shimano SLX, Shadow Plus
Cassett e Shimano HG50, 11-36, 10-speed
Crank Shimano M627, 36/22
Wheels Bontrager Duster Elite, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager XR3 Expert, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 29x2.40"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost KS eThirty Integra, remote lever, 2-bolt head,
31.6mm, zero offset, internal routing
Handlebar Bontrager alloy, 31.8mm, 5mm rise,
750mm width
Stem Bontrager Rhythm Comp, Knock Block, 31.8mm,
0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano M506 hydraulic disc
Key Features & Upgrades (?)
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP and
Full Floater
••Straight Shot stiffness, Knock Block
frame defence
RockShox Revelation RL fork
Fox Performance EVOL shock
Bontrager Duster Elite wheels
Shimano SLX/Deore drivetrain
