Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame and
seatstay, alloy chainstay, ABP, Boost148, Knock
Block steerer stop, Full Floater, EVO link, E2 tapered
head tube, Mino Link, Control Freak internal routing,
Carbon Armor, PF92, ISCG 05, G2 Geometry,
130mm travel
Front suspension Fox Performance 34 Float,
FIT4 3-position damper, E2 tapered steerer, Boost110,
G2 Geometry w/51mm offset, 140mm travel
Rear suspension Fox Performance Float EVOL,
RE:aktiv 3-position damper, tuned by Trek Suspension
Lab, 210x52.5mm
Shifters Shimano Deore XT M8000, 11-speed
Front derailleur Shimano Deore XT, high direct mount
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano Deore XT, 11-40, 11-speed
Crank Shimano Deore XT, 36/26
Wheels DT Swiss 350 Center Lock disc hubs,
Boost110 front, Boost148 rear; SUNringlé Duroc 40 SL
28-hole rims
Tyres Bontrager Chupacabra, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x2.80"
Saddle Bontrager Evoke 3, titanium rails
Seatpost RockShox Reverb Stealth, 2-bolt head,
31.6mm, zero offset
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm,
15mm rise, 750mm width
Stem Bontrager Line Pro, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Deore XT hydraulic disc
Key Features & Upgrades (?)
••New 130mm frame is more capable and 29"
or 27.5+ compatible
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
OCLV Mountain Carbon frame
Fox Performance Series fork and shock
DT Swiss 350 hubs
Shimano Deore XT 2x11 drivetrain
