Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame and
1x-specific stays, ABP, Boost148, Knock Block steerer
stop, Full Floater, EVO link, E2 tapered head tube,
Mino Link, Control Freak internal routing, Carbon
Armor, PF92, ISCG 05, 150mm travel
Front suspension RockShox Lyrik RCT3, Dual Position
Air, Charger Damper, E2 tapered steerer, Boost110,
130mm/160mm travel
Rear suspension RockShox Deluxe RT3, RE:aktiv
3-position damper, tuned by Trek Suspension
Lab, 230x57.5mm
Shifters SRAM X01 Eagle, 12-speed
Rear derailleur SRAM X01 Eagle, Roller
Bearing Clutch
Cassett e SRAM XG-1295, 10-50, 12-speed
Crank SRAM X01 Eagle, 32T Direct Mount X-Sync
Wheels Bontrager Line Elite 30, Tubeless Ready, 54T
Rapid Drive, Boost110 front, Boost148 rear
Tyres Bontrager SE4 Team Issue, Tubeless Ready, Core
Strength sidewalls, 120tpi, aramid bead, 27.5x2.40"
Saddle Bontrager Evoke 3, titanium rails
Seatpost Bontrager Drop Line 125, under-bar
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm,
27.5mm rise, 780 width
Stem Bontrager Line Pro, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset SRAM Guide Ultimate carbon hydraulic disc
Key Features & Upgrades (?)
••New 150mm frame optimised for Enduro and
technical trails
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Race Shop Limited: Pro-level builds
OCLV Mountain Carbon chainstay
RockShox Lyrik RCT3 dual-position fork
Bontrager Line Elite wheels
SRAM X01 Eagle 1x12 drivetrain
