Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame and
seatstay, alloy chainstay, ABP, Boost148, Knock
Block steerer stop, Full Floater, EVO link, E2 tapered
head tube, Mino Link, Control Freak internal routing,
Carbon Armor, PF92, ISCG 05, 150mm travel
Front suspension RockShox Pike RC, Solo Air, Charger
Damper, E2 tapered steerer, Boost110, 150mm travel
Rear suspension RockShox Deluxe RT3, RE:aktiv
3-position damper, tuned by Trek Suspension
Lab, 230x57.5mm
Shifters Shimano Deore XT M8000, 11-speed
Front derailleur Shimano Deore XT
Rear derailleur Shimano Deore XT, Shadow Plus
Cassett e Shimano Deore XT, 11-42, 11-speed
Crank Shimano Deore XT, 36/26
Wheels Bontrager Line Comp 30, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager XR4 Team Issue, Tubeless
Ready, Inner Strength sidewalls, 120tpi, aramid
bead, 27.5x2.40"
Saddle Bontrager Evoke 3, titanium rails
Seatpost Bontrager Drop Line 125, universal
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm,
27.5mm rise, 780 width
Stem Bontrager Line Pro, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Deore XT hydraulic disc
Key Features & Upgrades (?)
••New 150mm frame optimised for Enduro and
technical trails
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
OCLV Mountain Carbon frame
Shimano Deore XT 2x11 drivetrain
Shimano Deore XT brakes
Bontrager Line Pro handlebar and stem
