Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame Alpha Platinum Aluminium, ABP, Boost148,
Knock Block steerer stop, Full Floater, EVO link,
E2 tapered head tube, Mino Link, Control Freak
internal routing, downtube guard, PF92, ISCG 05,
150mm travel
Front suspension RockShox Lyrik RC, Dual Position
Air, Charger Damper, E2 tapered steerer, Boost110,
130mm/160mm travel
Rear suspension RockShox Deluxe RT3, RE:aktiv
3-position damper, tuned by Trek Suspension
Lab, 230x57.5mm
Shifters SRAM X1, 11-speed
Rear derailleur SRAM X1, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank SRAM X1 1200, 32T Direct Mount X-Sync
Wheels Bontrager Line Comp 30, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager SE4 Team Issue, Tubeless Ready, Core
Strength sidewalls, 120tpi, aramid bead, 27.5x2.40"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager Drop Line 125, under-bar
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line, 35mm, 27.5mm rise,
780 width
Stem Bontrager Line, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset SRAM Guide RS hydraulic disc
Key Features & Upgrades (?)
••New 150mm frame optimised for Enduro and
technical trails
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Race Shop Limited: Pro-Level Builds
RockShox Lyrik RC dual-position
fork 130/160mm
Bontrager Line Comp wheels
SRAM X1 drivetrain
SRAM Guide RS brakes
