Sizes 15.5, 17.5, 18.5, 19.5, 21.5"
Frame Alpha Platinum Aluminium, ABP, Boost148,
Knock Block steerer stop, Full Floater, EVO link,
E2 tapered head tube, Mino Link, Control Freak
internal routing, downtube guard, PF92, ISCG 05,
150mm travel
Front suspension RockShox Yari RL, Solo Air, Motion
Control damper, E2 tapered steerer, Boost110,
150mm travel
Rear suspension RockShox Deluxe RL, 230x57.5mm
Shifters Shimano Deore, 10-speed
Front derailleur Shimano Deore, low direct mount
Rear derailleur Shimano SLX, Shadow Plus
Cassett e Shimano HG50, 11-36, 10-speed
Crank Race Face Ride, 36/22
Wheels Bontrager Duster Elite, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager XR4 Expert, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x2.40"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost KS eThirty Integra, remote lever, 2-bolt head,
31.6mm, zero offset, internal routing
Handlebar Bontrager alloy, 31.8mm, 15mm rise
Stem Bontrager Rhythm Comp, Knock Block, 31.8mm,
0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Deore hydraulic disc
Key Features
••New 150mm frame optimised for Enduro and
technical trails
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP and
Full Floater
••Straight Shot stiffness, Knock Block
frame defence
