Sizes 15.5, 17.5, 18.5"
Frame Alpha Platinum Aluminium, ABP, Boost148,
Knock Block steerer stop, Full Floater, EVO link,
E2 tapered head tube, Mino Link, Control Freak
internal routing, downtube guard, PF92, ISCG 05,
150mm travel
Front suspension RockShox Pike RC, Solo Air, Charger
Damper, E2 tapered steerer, Boost110, 150mm travel
Rear suspension RockShox Deluxe RT3, RE:aktiv
3-position damper, tuned by Trek Suspension
Lab, 230x57.5mm
Shifters SRAM GX, 11-speed
Rear derailleur SRAM GX, Roller Bearing Clutch
Cassett e SRAM XG-1150, 10-42, 11-speed
Crank SRAM GX 1000, 32T X-Sync
Wheels Bontrager Duster Elite, Tubeless Ready,
Boost110 front, Boost148 rear
Tyres Bontrager XR4 Expert, Tubeless Ready, Inner
Strength sidewalls, aramid bead, 27.5x2.40"
Saddle Bontrager Evoke 1.5 WSD
Seatpost KS eThirty Integra, remote lever, 2-bolt head,
31.6mm, zero offset, internal routing
Handlebar Bontrager Line, 35mm, 27.5mm rise,
780 width
Stem Bontrager Line, Knock Block, 35mm, 0 degree
Headset Knock Block integrated, sealed cartridge
bearing, 1-1/8" top, 1.5" bottom
Brakeset Shimano Deore hydraulic disc
Key Features
••New 150mm frame optimised for Enduro and
technical trails
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••Exclusive suspension tech with ABP, Full
Floater and RE:aktiv
••Straight Shot stiffness, Knock Block
frame defence
