Sizes 15.5, 17.5, 19.5, 21.5"
Frame OCLV Mountain Carbon main frame and
1x-specific stays, ABP, Boost148, Knock Block steerer
stop, EVO link, E2 tapered head tube, Mino Link,
Control Freak internal routing, Carbon Armor, PF92,
ISCG 05, G2 Geometry, 160mm travel
Front suspension Fox Factory 36 Talas, high/
low speed compression adjust, E2 tapered
steerer, Boost110, G2 Geometry w/51mm offset,
130/160mm travel
Rear suspension Fox Factory Float X2, 2-position
damper, high/low speed rebound adjust, high/low
speed compression adjust, tuned by Trek Suspension
Lab, 230x57.5mm
Shifters SRAM X01 Eagle, 12-speed
Rear derailleur SRAM X01 Eagle, Roller
Bearing Clutch
Cassett e SRAM XG-1295, 10-50, 12-speed
Crank SRAM X01 Eagle, 32T Direct Mount X-Sync
Wheels Bontrager Line Elite 30, Tubeless Ready, 54T
Rapid Drive, Boost110 front, Boost148 rear
Tyres Bontrager SE4 Team Issue, Tubeless Ready, Core
Strength sidewalls, aramid bead, 29x2.40"
Saddle Bontrager Evoke 3, titanium rails
Seatpost Bontrager Drop Line 125, under-bar
remote lever, 2-bolt head, 31.6mm, zero offset,
internal routing
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm,
27.5mm rise, 780mm width
Stem Bontrager Line Pro, Knock Block, 35mm, 0 degree
Headset FSA Knock Block IS-2, E2, sealed
alloy cartridge
Brakeset SRAM Guide Ultimate carbon hydraulic disc
Key Features & Upgrades (?)
••150/160mm travel + 29er speed + low and
long geo = Enduro weapon
••Boost148/110: stronger wheels, more tyre
clearance, shorter stays
••ABP keeps your suspension active while
you’re on the brakes
••Race Shop Limited: Pro-level builds for the
most discerning riders
Fox Factory Float X2 shock
Fox Factory 36 Talas fork
Bontrager Line Elite 30 wheels
SRAM X01 Eagle 1x12 drivetrain
